HZS50 PLANT
Capacity : 50m³/h
Power : 1025KW
Discharge height : 1.5~4.2（m）
Price : 65000 - 75000USD
Get a quoteWhatsAppThe HZS50 concrete batching plant has a theoretical production rate of 50 cubic meters per hour. It is equipped with a JS1000 compulsory mixer as the mixing host, a PLD1600 batching machine for accurate measurement, and an LSY250 spiral conveyor. It is a semi-automatic concrete batching equipment composed of feeding, batching, mixing, electrical control, and steel structure components. This mixing plant has the advantages of low capital investment, small footprint, minimal equipment requirements, and the ability to produce high-quality and efficient concrete when the batching machine ensures accurate measurement. It is suitable for small-scale construction sites, precast factories, and commercial concrete production plants.
Technical Specifications
| Model | HZS25 | HZS35 | HZS50 | HZS75 | |
| Theoretical production capacity(m³/h) | 25 | 35 | 50 | 75 | |
| Concrete mixer | Type | JS500 | JS750 | JS1000 | JS1500 |
| Power(KW) | 24.75 | 38.6 | 51 | 65.5 | |
| Discharging capacity(L) | 500 | 750 | 1000 | 1500 | |
| Aggregate size(Pebble/Macadam)(mm) | 80/60 | 80/60 | 80/60 | 80/60 | |
| Aggregate Bin volume(m³) | 2/3×3.2 | 2/3/4×7.3 | 2/3/4×8.3 | 2/3/4×12 | |
| Weighing Accuracy | Aggregate (KG) | 1500Kg ±2% | 2200Kg ±2% | 3000Kg ±2% | 4500Kg ±2% |
| Cement(KG) | 300Kg ±1% | 450Kg ±1% | 600Kg ±1% | 1500Kg ±1% | |
| Fly ash(KG) | 400Kg ±1% | 600Kg ±1% | |||
| Water (KG) | 200Kg ±1% | 200Kg ±1% | 400Kg ±1% | 600Kg ±1% | |
| Additive(KG) | 30Kg ±1% | 50Kg ±1% | 50Kg ±1% | ||
| Discharging height(M) | 3.8 m | 3.8 m | 3.8 m | 4.1m | |
| Gross weight(T) | 10 | 15 | 40 | 50 | |
